5
Daintree
™
Controls
|
WHS20/WHR1
User Manual
|
V1.0
Using the remote control
The WHR1 is an intuitive commissioning tool that can be used
to communicate with Daintree ONE devices. Simply point the
remote at the Daintree sensor you would like to commission and
use the multi-directional touch pad to make the appropriate
changes. Scroll left to right, or up and down to navigate the menu
items and programming options. Use the center of the touch pad
to make final selections and save profile parameters.
Scroll the touch pad up and down to Select
from the following settings:
Dimming Function
• Max/Min Output
Occupancy Detection
• Occupied/Idle/Vacant Output
• Occupied/Idle Time
• Occupancy Sensitivity
• Occupancy Transition Rise/Fall Time
Ambient Light Detection
• Low/High Ambient Threshold
• High Ambient Output
• Ambient Light Sensitivity
• Ambient Light Transition Time
iBeacon Function
Power-On Configuration
• Power-On Output
• Power-On Duration
Multi-directional
Touch Pad
Once the function
is selected, toggle
right to select and
adjust the lighting
parameters.
To Next Page
