SK2019 FMCD-V-ECM-001
Actuator
Model
DR-16-230B
DR-16-24B
DR-15B-24B
Normal closed
Normal closed
Normal closed
Voltage
230Vac
24Vac
24Vac
Working force
90~125N
90~125N
90~125N
Time
4.5min
4.5min
4.5min
Power
3W
3W
3W
Full stroke
3.5mm
3.5mm
5.0mm
Imax
150mA
250mA
250mA
Wires
2-wire
2-wire
3-wire (red, blue, black)
