Daitsu FMCD-04 - Valve Information (Optional)

Page 14 of 59
Page 14 of 58
SK2019 FMCD-V-ECM-001
Valve Information (Optional)
2-Way Valve Body
3-Way Valve Body
Valve Code
(valve body + ON/ OFF
thermoelectric actuator)
Valve Body Dimensions (mm)
DN
A
B
C
D
SGS14HFCA-23020101
D15
(G1/2”)
52
47
19.5
63
Valve Code
(valve body + ON/ OFF
thermoelectric actuator)
Valve Body Dimensions (mm)
DN
A
B
C
D
SGS14HFCA-23020102
D15
(G1/2”)
52
70
40
86
