Daitsu FMCD-04 - Sensor Resistance R-T Conversion Table

Page 56 of 58
SK2019 FMCD-V-ECM-001
Resistance: R (25°C) = 10KΩ ± 1%
Beta Constant: B (25/85) = 3977 ± 1%
T
Rmin
Rnom
Rmax
T
Rmin
Rnom
Rmax
(°C)
(KΩ)
(KΩ)
(KΩ)
(°C)
(KΩ)
(KΩ)
(KΩ)
-30
174
182.7
191.8
4
26.11
26.9
27.71
-29
163.4
171.5
179.9
5
24.85
25.59
26.34
-28
153.6
161.1
168.9
6
23.65
24.35
25.05
-27
144.4
151.3
158.5
7
22.52
23.17
23.83
-26
135.8
142.2
148.9
8
21.45
22.06
22.68
-25
127.8
133.8
140
9
20.44
21.01
21.59
-24
120.3
125.8
131.6
10
19.48
20.02
20.55
-23
113.3
118.4
123.8
11
18.58
19.7
19.58
-22
106.7
111.5
116.5
12
17.71
18.18
18.65
-21
100.6
105.1
109.7
13
16.9
17.33
17.77
-20
94.9
99.03
103.3
14
16.12
16.53
16.94
-19
89.51
93.39
97.41
15
15.39
15.77
16.16
-18
84.5
88.11
91.85
16
14.69
15.05
15.41
-17
79.8
83.17
86.64
17
14.03
14.37
14.7
-16
75.39
78.53
81.76
18
13.41
13.72
14.03
-15
71.26
74.18
77.19
19
12.81
13.1
13.4
-14
67.37
70.1
72.9
20
12.24
12.52
12.79
-13
63.73
66.26
68.88
21
11.7
11.96
12.22
-12
60.3
62.67
65.1
22
11.19
11.43
11.67
-11
57.08
59.28
61.55
23
10.71
10.93
11.15
-10
54.05
56.1
58.22
24
10.24
10.45
10.66
-9
51.19
53.12
55.08
25
9.8
10
10.2
-8
48.51
50.3
52.14
26
9.374
9.57
9.765
-7
45.98
47.66
49.37
27
8.969
9.16
9.351
-6
43.61
45.17
46.77
28
8.584
8.77
8.957
-5
41.36
42.82
44.31
29
8.218
8.4
8.582
-4
39.25
40.61
42
30
7.869
8.047
8.225
-3
37.26
38.53
39.83
31
7.537
7.71
7.885
-2
35.38
36.56
37.78
32
7.221
7.39
7.56
-1
33.6
34.71
35.85
33
6.92
7.085
7.251
0
31.93
32.97
3402
34
6.633
6.794
6.956
1
30.35
31.32
32.3
35
6.36
6.517
6.675
2
28.85
29.76
30.68
36
6.099
6.252
6.407
3
27.44
28.29
29.15
37
5.85
6
6.151
