Product range: FMCD-ECM Hydronic High Wall with EC Motor
FMCD-[Size]-V~-ECM
18
20
24B
30
Unit Configuration
Configuration
2-pipe
Number Of Fan Blowers
Single
Power Supply
(V/Ph/Hz)
230/1/50
220/1/60
Operation Control
TOTAL: Complete function onboard PCB with integrated group control functionality, incl. 1 pc
return air sensor and 2 pcs temperature sensors.
FLEXI: Flexible function onboard PCB with louver and zone control functionality, incl. 1 pc coil
temperature sensors.
Performance Data
Air
Air Flow
H
m
3
/hr
788
980
1080
1240
M
740
760
980
1080
L
570
600
600
760
Cooling
Cooling Capacity
e
H
kW
3.71
4.81
5.33
5.93
M
3.26
3.9
4.78
5.12
L
2.66
3.35
3.33
3.88
Sensible Cooling Capacity
e
H
2.74
3.46
3.88
4.34
M
2.4
2.8
3.46
3.73
L
1.94
2.38
2.38
2.8
Latent Cooling Capacity
H
0.97
1.35
1.45
1.59
M
0.86
1.1
1.32
1.39
L
0.72
0.97
0.95
1.08
FCEER
e
Rating
181.35
208
165.52
141.61
Class
B
A
B
B
Heating
Heating Capacity
e
H
kW
4.06
5.97
5.64
6.3
M
3.86
4.82
5.21
5.64
L
3.12
4.12
3.48
4.23
Max. Electric Heater Capacity
1.5
FCCOP
e
Rating
214.87
258.09
176.34
156.2
Class
B
B
B
C
Sound
Sound PressureLevel( Outlet )
dB(A)
49/44/37
47/39/36
47/44/37
50/47/40
Sound Power Level ( Outlet )
e
58/53/46
56/48/45
56/53/46
58/56/49
Electrical
Power input in cooling mode
e
H
W
30
30
40
50
M
20
20
30
40
L
13
15
19
25
Power input in heating mode
e
H
W
30
30
40
50
M
20
20
30
40
L
13
15
19
25
Fan Motor Running Current @ H
A
0.26
0.26
0.35
0.43
Hydraulic
Cooling Water Flow Rate
H
L/h
638
816
916
1014
M
559
662
816
881
L
456
573
573
662
Cooling Pressure Drop
e
H
kPa
50
59.5
52.5
63.3
M
40
42.7
43.5
49.3
L
28
32.2
23.5
30.5
Heating Water Flow Rate
H
L/h
679
848
916
1012
M
650
705
848
916
L
538
589
589
705
Heating Pressure Drop
e
H
kPa
51.5
58.4
51.4
62.4
M
46.4
41.9
44.5
51.3
L
32.1
31.6
22.6
31.3
Water Content
L
0.192
0.252
0.252
0.252
Construction
and Packing Data
Water
Connections
Type
Socket (Threaded Female)
In
mm [in]
12.7 [1/2]
Out
Condensate Drainage Connection
16 [5/8]
Dimensions
L
mm
876
1063
W
228
240
H
300
310
Net Weight
kg
14
16
16
16
"e": Above specifications are based on the published Eurovent test data of the year of publication of this document. To confirm the most
updated specifications please visit www.eurovent-certification.com.
Eurovent testing conditions:
a. Cooling mode (2-pipe):
b. Heating mode (2-pipe):
- Return air temperature: 27C DB/ 19C WB.
- Return air temperature: 20C.
- Inlet/ Outlet water temperature: 7C/ 12C.
- Inlet/ Outlet water temperature: 45C/ 40C.
