S3-x0-0xk40 Interface Parameters (PRELIMINARY)
Table 21: Framegrabber Interface Parameters
Item (when
programmable
configuration the
options are
separated with a | )
S3-10-01k40 S3-20-01k40 S3-10-02k40 S3-20-02k40 S3-20-04k-40
Imager Dimension <1,2
or 1|2>
1 1 1 1 1
Imager
Columns<number of
active columns, X>
1024 1024 2048 2048 4096
Imager Rows<number of
active rows, Y> Line
Scan/TDI are defined as
1
1 1 1 1 1
Number of CCD Taps
<1,2,3…..>
1 2 1 2 2
Sensor Tap Clock Rate
<xx MHz>
40 40 40 40 40
Camera Standard
<NTSC, PAL, VS, VW,
MW>
VS VS VS VS VS
Variable Window
<Column Start, Column
End, Row Start, Row
End>
(0,0,0,0)
All zeros
indicates an
unsupported
feature
(0,0,0,0)
All zeros
indicates an
unsupported
feature
(0,0,0,0)
All zeros
indicates an
unsupported
feature
(0,0,0,0)
All zeros
indicates an
unsupported
feature
(0,0,0,0)
All zeros
indicates an
unsupported
feature
Multiple Window
Number of Windows
(Column Start 1, Column
End 1, Row Start 1, Row
End 1) (Column Start 2,
Column End 2,...)
0, (0,0,0,0)
All zeros
indicates an
unsupported
feature
0, (0,0,0,0)
All zeros
indicates an
unsupported
feature
0, (0,0,0,0)
All zeros
indicates an
unsupported
feature
0, (0,0,0,0)
All zeros
indicates an
unsupported
feature
0, (0,0,0,0)
All zeros
indicates an
unsupported
feature
Number of Camera
Configurations<1,2,3,…>
2 2 2 2 2
Configuration Definition
Cx= HDW, Number of
Output Taps, Bit Width,
Number of Processing
Nodes where
Cx is the configuration ID
x is <1,2,3…>
HDW is <Base,
Medium, Full>
Number of Output Taps
is <1,2,3…>
Bit width is <8, 10,
12…>
Number Processing
Nodes is <1 or 2>
C1 = Base, 1, 8, 1
C2 = Base, 1, 12, 1
C1 = Base, 2, 8, 1
C2 = Base, 2, 12,
1
C1 = Base, 1, 8, 1
C2 = Base, 1, 12,
1
C1 = Base, 2, 8, 1
C2 = Base, 2, 12, 1
C1 = Base, 2, 8, 1
C2 = Base, 2, 12, 1
