Spyder 3 CL User's Manual PRELIMINARY 31
DALSA 03-032-20008-03
4 Optical, Mechanical,
and Electrical
Considerations
4.1 Mechanical Interface
Figure 20: S3 1k and 2k Mechanical Dimensions
(49.6)
(53.9)
6.56
± 0.25
TOCCD
IMAGING
SENSOR
(19.4)
(33.7
)
(11.6)
42.0
(60.0)
57.0
(7.5)
(72.0)
M42x1THREAD
DEEP4.0
M3x0.5 THREAD
DEEP5.0(4X)
(9.0)
PIXEL1
30.000
± 0.050
CCDIMAGING
CENTER
36.000 ± 0.050
CCDIMAGING
CENTER
(30.1)
M3x0.5 THREAD
DEEP5.0(4X)
(14.0)
32.0
6.0
Units: mm
