Dalsa Spyder 3 S3-10-01k40-00-R User Manual

Spyder 3 CL User's Manual PRELIMINARY 7
DALSA 03-032-20008-03
1.2 Camera Performance Specifications
Table 2: Camera Performance Specifications
Feature / Specification Units 1k 2k 4k
Imager Format dual line scan dual line scan dual line scan
Resolution pixels 1024 2048 4096
Pixel Fill Factor % 100 100 100
Pixel Size µm 14x14 14x14 10x10
Sensitivity Mode High, low, or tall
pixel
High, low, or
tall pixel
High, low, or tall
pixel
Antiblooming 100x 100x 100x
Gain Range dB ±10 ±10 ±10
Optical Interface Units
Back Focal Distance
M42x1 mm 6.56±0.25
Lens mount adapters are available. Contact Sales for
more information.
Sensor Alignment
x
y
z
0z
µm
µm
mm
°
±50
±50
±0.25
±0.2
Mechanical Interface Units 1k and 2k 4k
Camera Size mm 72(h) x 60(l) x 50(w) 65(h) x 53.7(l) x 85(w)
Mass g <300 300
Connectors
power connector
data connector
6 pin male Hirose
MDR26 female
Electrical Interface Units
Input Voltage Volts +12 to +15
Power Dissipation W <5 (1k and 2k) <7 (4k)
Operating Temperature °C 0 to 50
Bit Width Bits 8 or 12 bit user selectable
Output Data Configuration Base
Camera Link
Speed 1k 2k 4k
Maximum Line Rate 2 tap model 68 kHz (80
MHz)
36 KHz (80
MHz)
18.5 kHz
1 tap model 36 (40 MHz) 18.5 (40 MHz)
