8 PRELIMINARY Spyder 3 CL User's Manual
03-032-20008-03 DALSA
Table 3: Camera Operating Specifications
Specifications Unit -10dB 0dB +10dB
Min Typ Max
Min Typ Max Min Typ Max
Broadband
responsivity
DN/(nJ/cm²)
Dual line 652.8 2064 6528
Single line 326.4 992 3264
4k Dual line 326.4±2 1032±5 3264±16
4k Single line 163.2±2 516.8±5 1632±16
Random noise rms DN 3 6.5 9.2 20.5 30 65
Dynamic range DN:DN
Dual line 500:1 1400:1 203:1 324:1 59:1 108:1
Single line 500:1 1400:1 203:1 324:1 59:1 108:1
4k Dual and Single 160:1 160:1 160:1
FPN global DN p-p
Uncorrected 52.8 169.6 536
Corrected 32 32 64
PRNU ECD
Uncorrected local % 8.5 8.5 11.5
Uncorrected global % 10 10 10
Corrected local DN p-p 80 80 95
Corrected global DN p-p 80 80 95
PRNU ECE
Uncorrected local % 8.5 12 37
Uncorrected global % 10 12 37
Corrected local DN p-p 80 237 752
Corrected global DN p-p 80 208 752
SEE (calculated) nJ/cm²
Dual line 6.35 1.92 0.61
Single line 12.2 4.0 1.2
NEE (calculated) pJ/cm²
Dual line 4.6 4.5 4.6
Single line 9.2 9.3 9.2
Saturation output
amplitude
DN 3968±80
DC offset DN 96 160 336
Test conditions unless otherwise noted:
• 12-bit values, Flat Field Correction (FFC) enabled.
• CCD Pixel Rate: 40 Megapixels/second per sensor tap.
• Line Rate: 5000 Hz.
• Nominal Gain setting unless otherwise specified.
• Light Source: Broadband Quartz Halogen, 3250k, with 750 nm highpass filter
installed.
• Ambient test temperature 25 °C.
• Unless specified, all values are referenced at 12 bit.
To Next Page
