18 PRELIMINARY Spyder 3 CL User's Manual
03-032-20008-03 DALSA
Table 7: Camera Link Connector Pinout
Base Configuration
One Channel Link Chip + Camera
Control + Serial Communication
Camera
Connector
Right Angle
Frame
Grabber
Channel
Link Signal
1 1 inner shield
14 14 inner shield
2 25 X0-
15 12 X0+
3 24 X1-
16 11 X1+
4 23 X2-
17 10 X2+
5 22 Xclk-
18 9 Xclk+
6 21 X3-
19 8 X3+
7 20 SerTC+
20 7 SerTC-
8 19 SerTFG-
21 6 SerTFG+
9 18 CC1-
22 5 CC1+
10 17 CC2+
23 4 CC2-
11 16 CC3-
24 3 CC3+
12 15 CC4+
25 2 CC4-
13 13 inner shield
26 26 inner shield
Notes:
*Exterior Overshield is connected to the shells of the connectors on both ends.
**3M part 14X26-SZLB-XXX-0LC is a complete cable assembly, including connectors.
Unused pairs should be terminated in 100 ohms at both ends of the cable.
Inner shield is connected to signal ground inside camera
Table 8: DALSA Camera Control Configuration
Signal Configuration
CC1 EXSYNC
CC2 PRIN
CC3 Direction
CC4 Spare
