1.2 Camera Performance Specifications
Table 2: Spyder3 GigE Vision Camera Performance Specifications
Feature / Specification 1k 2k 4k
Imager Format dual line scan dual line scan dual line scan
Resolution 1024 pixels 2048 pixels 4096 pixels
Pixel Fill Factor 100 % 100 % 100 %
Pixel Size 14 x 14 µm 14 x 14 µm 10 x 10 µm
Output Format (# of taps) 1 or 2
depending on
model
1 or 2
depending on
model
2
Sensitivity Mode High, low, or tall
pixel
High, low, or
tall pixel
High, low, or tall
pixel
Antiblooming 100x 100x 100x
Gain Range -10 to 10 dB -10 to 10 dB -10 to 10 dB
Optical Interface
Back Focal Distance
M42x1
6.56±0.25 mm
Lens mount adapters are available. Contact Sales for more
information.
Sensor Alignment
x
y
z
Υz
±50 µm
±50 µm
±0.25 mm
±0.2°
Mechanical Interface 1k and 2k 4k
Camera Size 72(h) x 60(l) x 50(w) mm 65(h) x 58(l) x 85(w)
mm
Mass < 300 g
Connectors
power connector
GigE connector
GPI/O connector
6 pin male Hirose
RJ45
High density 15-pin dsub
Electrical Interface
Input Voltage +12 to +15 volts
Power Dissipation < 9 W < 9 W (4k)
Operating Temperature 0 to 50 °C
Bit Width 8 or 12 bit, user selectable
Output Data Configuration GigE
Speed 1k 2k 4k
Minimum Internal Line Rate 300 Hz 300 Hz 300 Hz
Maximum Line Rate
80 MHz model
68 kHz 36 kHz 18.5 kHz
40 MHz model
36 18.5 NA
