Spyder3 GigE Vision User’s Manual
DALSA 03-032-20027-02
5
1
Spyder3 GigE Vision
Camera
1.1 Camera Highlights
Features and Programmability
• Broadband responsivity up to 408±16DN(nJ/cm
2
) @ 10dB gain
• 1024, 2048, or 4096 pixels, 14µm x 14µm (1k and 2k) and 10µm x 10µm (4k) pixel
pitch, 100% fill factor
• High or low speed (40 or 80 MHz)
• Up to 68 KHz line rates
• Dynamic range up to 1400 : 1
• Data transmission up to 100m
• ±50µm x, y sensor alignment
• RoHS and CE compliant
• Easy-to-use graphical user interface
• Serial interface (ASCII, 9600 baud, adjustable to 19200, 57600, 115200), through virtual
serial port through Ethernet
• Programmable gain, offset, exposure time and line rate, trigger mode, test pattern
output, and camera diagnostics
• Tall pixel, high sensitivity, or low sensitivity mode available.
• Flat-field correction—minimizes lens vignetting, non-uniform lighting, and sensor
FPN and PRNU.
