Dalsa Spyder3 SG-11-01k40-00-R User Manual

Spyder3 GigE Vision User Manual
03-032-20027-02 DALSA
12
1.4 Responsivity
Figure 6: Spyder3 GigE Vision 1k and 2k Responsivity
Spectral Responsivity. Nominal Gain
0
250
500
750
1000
1250
1500
1750
2000
2250
2500
400 500 600 700 800 900 1000 1100
Wavelength (nm)
Responsivity {DN/(nJ/cm²)}
High Sensitivity Mode
Low Sensitivity Mode
Figure 7: Spyder3 GigE Vision 4k Responsivity
SG-11-04K80-00-R Spectral Responsivity
@ 0 dB gain
0
200
400
600
800
1000
1200
1400
1600
1800
2000
400 500 600 700 800 900 1000 1100
Wavelength (nm)
Responsivity
12 bits DN/nJ/cm2
Low Sensitivity Mode
Hi Sensitivity Mode
Refer to section 1.3 Image Sensor for a description of high and low sensitivity modes.
