Dane Technologies, Inc. WheelChair Mover Owners Manual 37
7105 Northland Terrace, Minneapolis, MN 55428 / 888-544-7779 / 763-544-7779 / Fax 763-544-4234
www.danetechnologies.com 970-068 6/19/17 Rev F
Turn off the red service maintenance switch and remove the key.
Remove the bolts for the front cover and side cover on the left side of the drive
wheel and remove the covers. CAUTION: The cover may have weights attached and
can be heavy (up to 28 lbs).
Using a 17mm wrench, slightly loosen the shaft nut on the wheel.
In a clear open area, use the handlebars to pull the machine to its right side and lay
it down on the floor.
Power control and Emergency Off. Also
called the Service Maintenance Key.
