Standards and Testing
Note:
The Wheelchair Mover is designed to assist the
movement of patients in manual wheelchairs.
The Wheelchair Mover, by itself, does not provide
treatment to the operator or the patient. The Wheelchair
Mover reduces the operating forces when moving
patients in manual wheelchairs and may be used in the
treatment of an operator’s condition.
Manufacturer Specifications:
Manufacturer: Dane Technologies Inc.
7105 Northland Terrace
Brooklyn Park, MN 55428
763-544-7779
Model: WheelChair Mover
Maximum occupant mass (including wheelchair):
Standard - 550 lbs (250 kg) All testing completed with 550 lbs test dummy.
Bariatric – 750 lbs (340 kg). All testing completed with a 750 lbs test dummy.
Measurements Specifications
Parameter
Standard
Bariatric
Overall Length
27.6 in (.70 m)
Overall Width
23.6 in (.60 m)
Overall Height
42.5 in (1.08 m)
Maximum Patient Weight
550 lbs (250 kg)
750 lbs (341 kg)
Total WCM Weight
334 lbs (151 kg)
370 lbs (168 kg)
Dynamic Stability Uphill
Up to 10
Up to 8.3
Obstacle traverse Forward
1.57 in (40 mm)
Obstacle traverse Rearward
.47 in (12 mm)
Ground Clearance
2.63 in (66 mm)
Maximum Speed Forward
2.5 mph (4 km/hr)
Maximum Reverse Speed
1.6 mph (2.6 km/hr)
Minimum outside Turning Radius
24 in (.61 m)
Turnaround between limiting walls,
WCM only
48 in (1.22 m)
Operating Temperature test range
-13 to 122 F (-25 to 50 C)
Storage Temperature test range
-40 to 149 F (-40 to 65 C)
Drive Wheel Diameter
9 in (228 mm)
Drive Wheel inflation
Foam filled
Caster wheel Diameter
4 in (101 mm)
Caster wheel inflation
Solid tire
Braking Distance forward-level to 6
4.4 ft (1.34 m)
5.7 ft (1.73 m)
