To store the IV Pole Holder:
Maintaining the IV Pole Holder:
The IV Pole Holder is designed for years of trouble free use. If you find, however, that
an IV pole does not maintain its position when the WheelChair Mover is in motion, then
the IV Pole Holder pivot bolt needs to be tightened.
1. Using a ¾-inch socket and a torque wrench, tighten pivot bolt to 22 ft-lbs torque.
To store IV Pole Holder,
rotate up and slide down
