BAM comm. timeout
been interrupted.
190
DPU
CPU fan failed
The primary fan in the DPU has failed. The secondary fan in DPU
will serve as a backup until the problem is rectified. The VDR will
be able to operate normally unless the secondary fan also fails
(error 191). This problem must be rectified latest at the next APT.
191
DPU
Backup fan failed
The secondary fan in the right side of the DPU has failed. This is
only a major problem if also the primary fan has failed (error 190).
300-
307
SERIAL
Timeout on SIxx
Mandatory serial data is not received. Check that the source is on.
Check the signal from the source (serial monitor in VDR explorer,
WEB status or VGA status display). If no signal is present check
the cable and make sure that the configuration is correct.
320-
335
NETWORK Channel
Timeout on NI2xx
Mandatory network data is not received on channel NI2xx. Check
that the source is switched on and active, check the cable and that
the VDR configuration is correct.
360-
375
NETWORK Channel
Excess Data on NI2xx
Too much network data is currently received on channel NI2xx.
Check that the source is operating correctly. The VDR Explorer
may be used to monitor the data.
400-
423
SERIAL
Timeout on SIxx
Mandatory serial data is not received. Check that the source is on.
Check the signal from the source (serial monitor in VDR explorer,
WEB status or VGA status display). If no signal is present check
the cable and make sure that the configuration is correct.
441
SERIAL module 2
Missing (SI08-12)
For a DM100, the second serial module is integrated on the SAP
board in the DPU. The most probable cause is that the SAP board
in the DPU is defective.
442
ANALOG module 1
Missing (AN00-15)
If only one module is affected:
A module has been removed or has failed. Check that the module is
installed correctly.
If installed in a modular SIU the blue “link” LED for the module
must be illuminated. If the LED is already illuminated switch the
power to the SIU off and on. If the error persists replace the
module.
If all modules in a SIU are affected:
Check the power to the SIU.
Check the cable from the SIU to the DAU and link status; see
section 4.1.7, 5.1.3 and 6.1.4.
If no error is found, try to restart both the DAU and the SIU (power
off and then on)
If the error persists, the DPU or the Module rack/Uni rack is
probably defective.
443
DIGITAL module 1
Missing (DI00-15)
444
DIGITAL module 2
Missing (DI16-31)
445
DIGITAL module 3
Missing (DI32-47)
446
DIGITAL module 4
Missing (DI48-63)
450-
452
SIU xxxxxxx
Module in wrong slot
xxxxxxx = SERIAL, ANALOG, DIGITAL
A module has been misplaced. Modules must be installed
according to the VDR configuration.
460-
462
SIU xxxxxxx
Wrong MR address
xxxxxxx = SERIAL, ANALOG, DIGITAL
A SIU with the wrong Module Rack address has been detected. Set
the MR/UR address to 0 or 1. See section 6.1.6
470-
472
SIU xxxxxx
Module duplicate
xxxxxxx = SERIAL, ANALOG, DIGITAL
The VDR has detected two different modules with the same
MR/UR address and slot number. This may occur if two SIUs are
DBS11011-12 Page 22/27
