Instructions ECL Comfort 210 / 310, communication description
ECL Comfort Parameter Description PNU Access Scale
Schedule PNU 3110 - 3675
Schedule Monday circuit X period 1 start Monday P1 ON 3110 R/W
Schedule Monday circuit X period 1 stop Monday P1 OFF 3111 R/W
Schedule Monday circuit X period 2 start Monday P2 ON 3112 R/W
Schedule Monday circuit X period 2 stop Monday P2 OFF 3113 R/W
Schedule Monday circuit X period 3 start Monday P3 ON 3114 R/W
Schedule Monday circuit X period 3 stop Monday P3 OFF 3115 R/W
Schedule Tuesday circuit X period 1 start Tuesday P1 ON 3120 R/W
Schedule Tuesday circuit X period 1 stop Tuesday P1 OFF 3121 R/W
Schedule Tuesday circuit X period 2 start Tuesday P2 ON 3122 R/W
Schedule Tuesday circuit X period 2 stop Tuesday P2 OFF 3123 R/W
Schedule Tuesday circuit X period 3 start Tuesday P3 ON 3124 R/W
Schedule Tuesday circuit X period 3 stop Tuesday P3 OFF 3125 R/W
Schedule Wednesday circuit X period 1 start Wednesday P1 ON 3130 R/W
Schedule Wednesday circuit X period 1 stop Wednesday P1 OFF 3131 R/W
Schedule Wednesday circuit X period 2 start Wednesday P2 ON 3132 R/W
Schedule Wednesday circuit X period 2 stop Wednesday P2 OFF 3133 R/W
Schedule Wednesday circuit X period 3 start Wednesday P3 ON 3134 R/W
Schedule Wednesday circuit X period 3 stop Wednesday P3 OFF 3135 R/W
Schedule Thursday circuit X period 1 start Thursday P1 ON 3140 R/W
Schedule Thursday circuit X period 1 stop Thursday P1 OFF 3141 R/W
Schedule Thursday circuit X period 2 start Thursday P2 ON 3142 R/W
Schedule Thursday circuit X period 2 stop Thursday P2 OFF 3143 R/W
Schedule Thursday circuit X period 3 start Thursday P3 ON 3144 R/W
Schedule Thursday circuit X period 3 stop Thursday P3 OFF 3145 R/W
Schedule Friday circuit X period 1 start Friday P1 ON 3150 R/W
Schedule Friday circuit X period 1 stop Friday P1 OFF 3151 R/W
Schedule Friday circuit X period 2 start Friday P2 ON 3152 R/W
Schedule Friday circuit X period 2 stop Friday P2 OFF 3153 R/W
Schedule Friday circuit X period 3 start Friday P3 ON 3154 R/W
Schedule Friday circuit X period 3 stop Friday P3 OFF 3155 R/W
Schedule Saturday circuit X period 1 start Saturday P1 ON 3160 R/W
Schedule Saturday circuit X period 1 stop Saturday P1 OFF 3161 R/W
Schedule Saturday circuit X period 2 start Saturday P2 ON 3162 R/W
Schedule Saturday circuit X period 2 stop Saturday P2 OFF 3163 R/W
Schedule Saturday circuit X period 3 start Saturday P3 ON 3164 R/W
Schedule Saturday circuit X period 3 stop Saturday P3 OFF 3165 R/W
Schedule Sunday circuit X period 1 start Sunday P1 ON 3170 R/W
Schedule Sunday circuit X period 1 stop Sunday P1 OFF 3171 R/W
Schedule Sunday circuit X period 2 start Sunday P2 ON 3172 R/W
Schedule Sunday circuit X period 2 stop Sunday P2 OFF 3173 R/W
Schedule Sunday circuit X period 3 start Sunday P3 ON 3174 R/W
Schedule Sunday circuit X period 3 stop Sunday P3 OFF 3175 R/W
Schedule 2 - start
3210
Schedule 2 - end
3275
Schedule 3 - start
3310
Schedule 3 - end
3375
Schedule 4 - start
3410
Schedule 4 - end
3475
Schedule 5 - start
3510
Schedule 5 - end
3575
Schedule 6 - start
3610
Schedule 6 - end
3675
Danfoss District Energy VI.LG.V3.02 DEN-SMT/DK
37
