Instructions ECL Comfort 210 / 310, communication description
ECL Comfort Parameter Description PNU Access Scale
Output
Output bit mask High word (digital outputs) 3998
Output bit mask Low word (digital outputs 3999
Manual status, Triac 1 4020 R
Manual status, Triac 2 4021 R
Manual status, Triac 3 4022 R
Manual status, Triac 4 4023 R
Manual status, Triac 5 4024 R
Manual status, Triac 6 4025 R
Manual status, Relay 1 4026 R
Manual status, Relay 2 4027 R
Manual status, Relay 3 4028 R
Manual status, Relay 4 4029 R
Manual status, Relay 5 4030 R
Manual status, Relay 6 4031 R
Manual status, ECA32 Relay 1 4032 R
Manual status, ECA32 Relay 2 4033 R
Manual status, ECA32 Relay 3 4034 R
Manual status, ECA32 Relay 4 4035 R
Manual status, ECA32 AO1 4036
Manual status, ECA32 AO2 4037
Manual status, ECA32 AO3 4038
Manual values - reserve start 4040 R
Manual value, ECA32 AO1 …
Manual value, ECA32 AO1 4056
Manual value, ECA32 AO1 4057
4058
Manual values - reserve end 4059 R
Override status, Triac 1 4060 RW
Override status, Triac 2 4061 RW
Override status, Triac 3 4062 RW
Override status, Triac 4 4063 RW
Override status, Triac 5 4064 RW
Override status, Triac 6 4065 RW
Override status, Relay 1 4066 RW
Override status, Relay 2 4067 RW
Override status, Relay 3 4068 RW
Override status, Relay 4 4069 RW
Override status, Relay 5 4070 RW
Override status, Relay 6 4071 RW
Override status, ECA32 Relay 1 4072 RW
Override status, ECA32 Relay 2 4073 RW
Override status, ECA32 Relay 3 4074 RW
Override status, ECA32 Relay 4 4075 RW
Override status, ECA32 AO1 4076
Override status, ECA32 AO2 4077
Override status, ECA32 AO3 4078
Danfoss District Energy VI.LG.V3.02 DEN-SMT/DK
