AK-PC 783 Capacity controller RS8GN202 © Danfoss 11-2013 49
The connections for the example can be seen here.
Mounting and wiring - continued
The screen on the pressure
transmitter cables must only
be connected at the end of the
controller.
The supply voltage for the pressure
transmitter should be taken from
the same module that receives the
pressure signal.
Warning
Keep signal cables separate from
cables with high voltage.
To Next Page
