Danfoss ADAP-KOOL Drive User Manual

26-31 Terminal X42/5 High Voltage
Range: Function:
10.00 V* [par. 6-30 - 10.00 V] Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par.26-35
Term. X42/5 High Ref./Feedb. Value .
26-34 Term. X42/5 Low Ref./Feedb. Value
Range: Function:
0.000 N/A* [-999999.999 - 999999.999 N/A] Enter the analog input scaling value that corresponds to the low voltage value set in par.
26-30
Terminal X42/5 Low Voltage .
26-35 Term. X42/5 High Ref./Feedb. Value
Range: Function:
100.000 N/
A*
[-999999.999 - 999999.999 N/A] Enter the analog input scaling value that corresponds to the high voltage value set in par.
26-21
Terminal X42/3 High Voltage .
26-36 Term. X42/5 Filter Time Constant
Range: Function:
0.001 s* [0.001 - 10.000 s] Enter the time constant. This is a first-order digital low pass filter time constant for suppressing
noise in terminal X42/5. A high time constant value improves dampening but also increases the time
delay through the filter. This parameter cannot be adjusted while the motor is running.
26-37 Term. X42/5 Live Zero
Option: Function:
This parameter makes it possible to enable the Live Zero monitoring. E.g. where the analog input
is a part of the frequency converter control, rather than being used as part of a decentral I/O system,
such as a Building Management System.
[0] Disabled
[1] * Enabled
26-40 Terminal X42/7 Output
Option: Function:
Set the function of terminal X42/7 as an analog voltage output.
[0] * No operation
[100] Output frequency : 0 - 100 Hz, (0-20 mA)
[101] Reference : Minimum reference - Maximum reference, (0-20 mA)
[102] Feedback : -200% to +200% of par. CL-14
Maximum Reference/Feedb. , (0-20 mA)
[103] Motor current
[104] Torque rel to limit : 0 - Torque limit (par.4-16
Torque Limit Motor Mode ), (0-20 mA)
[105] Torq relate to rated : 0 - Motor rated torque, (0-20 mA)
[106] Power : 0 - Motor rated power, (0-20 mA)
[107] Speed : 0 - Speed High Limit (par.4-13
Motor Speed High Limit [RPM] and par.4-14 Motor Speed High Limit
[Hz]
), (0-20 mA)
[108] Torque
[109] Max Out Freq
[113] Ext. Closed Loop 1 : 0 - 100%, (0-20 mA)
[114] Ext. Closed Loop 2 : 0 - 100%, (0-20 mA)
[115] Ext. Closed Loop 3 : 0 - 100%, (0-20 mA)
3 Parameter Description ADAP-KOOL
®
Drive Programming Guide
214 MG.11.N1.02 - VLT
®
is a registered Danfoss trademark
3
