[139] Bus ctrl. : 0 - 100%, (0-20 mA)
[141] Bus ctrl t.o. : 0 - 100%, (0-20 mA)
26-41 Terminal X42/7 Min. Scale
Range: Function:
0.00 %* [0.00 - 200.00 %] Scale the minimum output of the selected analog signal at terminal X42/7, as a percentage of the
maximum signal level. E.g. if a 0 V (or 0 Hz) is desired at 25% of the maximum output value. Then
programme 25%. Scaling values up to 100% can never be higher than the corresponding setting
in par.26-42
Terminal X42/7 Max. Scale .
See principle graph for par.6-51
Terminal 42 Output Min Scale .
26-42 Terminal X42/7 Max. Scale
Range: Function:
100.00 %* [0.00 - 200.00 %] Scale the maximum output of the selected analog signal at terminal X42/7. Set the value to the
maximum value of the voltage signal output. Scale the output to give a voltage lower than 10V at
full scale; or 10V at an output below 100% of the maximum signal value. If 10V is the desired output
current at a value between 0-100% of the full-scale output, programme the percentage value in the
parameter, i.e. 50% = 10V. If a voltage between 0 and 10V is desired at maximum output, calculate
the percentage as follows:
(
10 V
desired
maximum voltage
)
x 100 %
i.e.
5 V :
10 V
5 V
× 100% = 200%
See principle graph for par.6-52 Terminal 42 Output Max Scale .
26-43 Terminal X42/7 Bus Control
Range: Function:
0.00 %* [0.00 - 100.00 %] Holds the level of terminal X42/7 if controlled by bus.
26-44 Terminal X42/7 Timeout Preset
Range: Function:
0.00 %* [0.00 - 100.00 %] Holds the preset level of terminal X42/7.
In case of a bus timeout and a timeout function is selected in par.26-50
Terminal X42/9 Output the
output will preset to this level.
26-50 Terminal X42/9 Output
Option: Function:
Set the function of terminal X42/9.
[0] * No operation
[100] Output frequency : 0 - 100 Hz, (0-20 mA)
[101] Reference : Minimum reference - Maximum reference, (0-20 mA)
[102] Feedback : -200% to +200% of par. CL-14
Maximum Reference/Feedb. , (0-20 mA)
[103] Motor current
[104] Torque rel to limit : 0 - Torque limit (par.4-16
Torque Limit Motor Mode ), (0-20 mA)
[105] Torq relate to rated : 0 - Motor rated torque, (0-20 mA)
[106] Power : 0 - Motor rated power, (0-20 mA)
[107] Speed : 0 - Speed High Limit (par.4-13
Motor Speed High Limit [RPM] and par.4-14 Motor Speed High Limit
[Hz]
), (0-20 mA)
[108] Torque
