*) Can only be set when regulation is stopped (r12=0)
**) Can be controlled manually, but only when r12=-1
***) With access code 2 the access to these menus will be limited
Forced control
If you need to force-control an output, you should set r12 to -1 (manual mode). You should then select
the relevant relay function, e.g. u58. Go to the function by pressing the middle button. Select On.
Conguration of alarm relay
The alarm relay will be activated upon an alarm signal
from the following groups:
1 - High temperature alarms
2 - Low temperature alarms
4 - Sensor error
8 - Digital input is activated for alarm
16 - Defrost alarms
32 - Miscellaneous
The groups that are to activate the alarm relay must be set
by using a numerical value which is the sum of the groups
that must be activated.
(E.g. a value of 5 will activate all high temperature alarms
and all sensor errors).
0 = Cancel relay function
P41 1 1 1 1 1 1
0 63 47
Service
Temperature measured with S5 sensor
u09 1 1 1 1 1 1 1 1 1
Status on DI1 input. on/1=closed
u10 1 1 1 1 1 1 1 1 1
Actual defrost time (minutes)
u11 1 1 1 1 1 1 1 1 1
Temperature measured with S3 sensor
u12 1 1 1 1 1 1 1 1 1
Status on night operation (on or o) 1=on
u13 1 1 1 1 1 1 1 1 1
Temperature measured with S4 sensor
u16 1 1 1 1 1 1 1 1 1
Thermostat temperature
u17 1 1 1 1 1 1 1 1 1
Run time of thermostat (cooling time) in minutes
u18 1 1 1 1 1 1 1 1 1
Temperature measured with S6 sensor
(product temperature)
u36 1 1 1 1 1 1 1 1 1
Status on DI2 output. on/1=closed
u37 1 1 1 1 1 1 1 1 1
Air temperature. Weighted S3 + S4
u56 1 1 1 1 1 1
Measured temperature for alarm thermostat
u57 1 1 1 1 1 1 1 1 1
Status on relay for cooling
** u58 1 1 1 1 1 1 1 1 1
Status on relay for fan
** u59 1 1 1 1 1 1 1 1 1
Status on relay for defrost
** u60 1 1 1 1 1 1 1 1
Status on relay for rail heat
** u61 1 1 1 1
Status on relay for alarm
** u62 1 1 1 1 1 1
Status on relay for light
** u63 1 1 1 1 1 1 1 1 1
Status on relay for valve in suction line
** u64 1
Status on relay for compressor 2
** u67 1 1
Temperature measured with S5B sensor
u75 1 1
Temperature measured with S3B sensor
u76 1 1 1
Temperature measured with S6B sensor
u79 1
Status on relay for hot gas- / drain valve
** u80 1
Status on relay for heating element in drip tray
** u81 1
Status on relay for night blinds
** u82 1
Status on relay for defrost B
** u83 1 1
Status on relay for heat function
** u84 1
Readout of the actual rail heat eect
u85 1 1 1 1
1: Thermostat 1 operating, 2: Thermostat 2 operating
u86 1 1 1 1 1 1 1 1 1
Status on high voltage input DI3
u87 1 1 1 1 1 1 1 1 1
Readout of thermostats actual cut in value
u90 1 1 1 1 1 1 1 1 1
Readout of thermostats actual cut out value
u91 1 1 1 1 1 1 1 1 1
Readout the brine PWM OD% U02 1 1 1 1 1 1 1 1 1
Continued Code 1 2 3 4 5 6 7 8 9 Min. Max. Fac. Actual
Factory setting
If you need to return to the factory-set values, it can be done in this way:
- Cut out the supply voltage to the controller
- Keep upper and lower button depressed at the same time as you reconnect the supply voltage
