Various alarms
Standby mode Medium Control stopped,
MainSwitch=OFF
The control has been stopped via the setting ”Main switch” = O or
the external Main switch is o
Max defrost periode
exceeded
Medium Max defrost periode ex-
ceeded
The defrost has stopped on max time and not on temperature
Thermostat x – Low
temp. alarm
Low Thermostat x - Low alarm The temperature for thermostat no. x has been below the low alarm
limit for longer time than set delay
Thermostat x – High
temp. alarm
Low Thermostat x - High alarm The temperature for thermostat no. x has been above the high alarm
limit for longer time than set delay
Pressostat x – Low pres-
sure alarm
Low Pressostat x - Low alarm The pressure for pressostat no. x has been below the low alarm limit
for longer time than set delay
Pressostat x – alarm limit
high pressure
Low Pressostat x - High alarm The pressure for pressostat no. x has been above the high alarm
limit for longer time than set delay
Voltage input x – Low
alarm
Low Analog input x - Low alarm The voltage signal has been below the low alarm limit for longer
time than set delay
Voltage input x – High
alarm
Low Analog input x - High alarm The voltage signal has been above the high alarm limit for longer
time than set delay
DIx alarm input Low Custom alarm x -dene text Alarm on general alarm input DI x
Low Extra cooling req. relay is ON The controller cannot keep the brine temperature down and has
activated the relay that activates extra cooling.
System alarms
The alarm priority can not be altered on system alarms
Low Refrigerant A not selected Refrigerant has not been selected
Low Refrigerant changed Refrigerant type has been changed
Medium Time has not been set Time has not been set
Medium System Critical exception A unrecoverable critical system failure has occurred – exchange the
controller
Medium System alarm exception A minor system failure has occurred – power o controller
Medium Alarm destination disabled When this alarm is activated the alarm transmission to the alarm
receiver has been deactivated. Check and wait.
When the alarm is cleared the alarm transmission to the alarm
receiver has been activated again
Medium Alarm route failure Alarms can not be transmitted to alarm receiver – check communi-
cation
High Alarm router full The internal alarm buer has an overrun – this might occur if the
controller can not send the alarms to the alarm receiver. Check com-
munication between controller and system unit.
Medium Device is restarting The controller is restarting after ash updating of the software
Medium I/O board failure There is a communication fault between the controller module and
the extension modules – the fault must be corrected as soon as
possible
Manual control
Low MAN DI………. The in put in question has been put in manual control mode via the
AK-ST 500 service tool software
Low MAN DO……… The output in question has been put in manual control mode via the
AK-ST 500 service tool software
