Danfoss APP series

64 | 180R9346 | AQ240486503020en-001702 © Danfoss | 2023.03
Operation guide Installation, Operation and Maintenance APP 53-92 pumps
BoWex-ELASTIC
®
Operating/Assembly instructions
Type HEW, HEW Compact and HEW-ZS
KTR-N
Sheet:
Edition:
40114 EN
4
of 22
7
Please observe protection
note ISO 16016.
Drawn:
2017-04-24 Shg/Hk
Replacing:
KTR-N dated 2013-06-10
Verified:
2017-04-24 Shg
Replaced by:
Table 2: Torques – type HEW1 and HEW2
Size
Elastomer
hardness
[Shore A]
Torque [Nm]
Size
Elastomer
hardness
[Shore A]
Torque [Nm]
T
KN
T
K max.
T
KN
T
K max.
42
40 / T40
130
390
125
40 / T40
3000
9000
50 / T50
150
450
50 / T50
4000
12000
65 / T65
180
540
65 / T65
5000
15000
48
40 / T40
200
600
G 125
40 / T40
4000
12000
50 / T50
230
690
50 / T50
5200
16000
65 / T65
280
840
65 / T65
6500
20000
65
40 / T40
350
1050
150
T40
5500
16500
50 / T50
400
1200
T50
7000
21000
65 / T65
500
1500
T65
9000
27000
80
40 / T40
750
2250
G 150
T40
7000
21000
50 / T50
950
2850
T50
9200
27600
65 / T65
1200
3600
T65
11500
34500
G 80
40 / T40
1250
3750
200
T40
9500
28500
50 / T50
1600
4800
T50
12500
37500
65 / T65
2000
6000
T65
16000
48000
100
40 / T40
2000
6000
G 200
T40
11500
34500
50 / T50
2500
7500
T50
15000
45000
65 / T65
3200
9600
T65
19500
58500
BoWex
®
HEW Compact
Illustration 3: BoWex-ELASTIC
®
type HEW1
Illustration 4: BoWex-ELASTIC
®
type HEW2
Table 3: Dimensions – type HEW Compact
Size
Max. finish
bore [mm]
Dimensions [mm]
Weight with
pilot bored
coupling [kg]
Mass moment of
inertia with pilot
bored coupling
[kgm
2
]
d
1
d
2
D
1
D
2
D
3
D
4
l
1
l
2
l
3
l
4
E
L
L
1
z
M
J
1
J
2
42-130
42
42
90
65
78
131
42
42
45
37
34
118
98
6
M6
3.4
0.003
0.001
65-180
65
65
130
96
110
180
60
55
55
47
30
145
122
8
M10
9.0
0.014
0.006
80-225
75
80
145
124
120
225
70
90
77
51
50
210
158
10
M12
18.9
0.035
0.029
100-305
100
100
200
152
175
305
90
110
90
73
58
258
187
16
M12
40.2
0.152
0.087
125-365
125
125
235
192
205
365
120
140
150
90
68
328
240
12
M16
75.0
0.36
0.26
1 Technical data
