Parameter 23-01 ON Action
Table 1022: Parameter 23-01 ON Action
23-01 ON Action
Default value: [0] Disabled
Parameter type: Option, Array [10]
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
N O T I C E
For options [32] Set digital out A low–[43] Set digital out F high, see also parameter group 5-3* Digital Outputs and parameter group
5-4* Relays.
Select the action during ON time. See parameter 13-52 SL Controller Action for descriptions of the options.
Option
Name
Description
[0]*
Disabled
[1]
No action
[2]
Select set-up 1
[3]
Select set-up 2
[4]
Select set-up 3
[5]
Select set-up 4
[10]
Select preset ref 0
[11]
Select preset ref 1
[12]
Select preset ref 2
[13]
Select preset ref 3
[14]
Select preset ref 4
[15]
Select preset ref 5
[16]
Select preset ref 6
[17]
Select preset ref 7
[18]
Select ramp 1
[19]
Select ramp 2
[20]
Select ramp 3
[21]
Select ramp 4
[22]
Run
[23]
Run reverse
[24]
Stop
[25]
Qstop
[26]
Dcstop
[27]
Coast
AU275636650261en-000101 / 130R0334552 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
