Option
Name
Description
[32]
Set digital out A low
[33]
Set digital out B low
[34]
Set digital out C low
[35]
Set digital out D low
[36]
Set digital out E low
[37]
Set digital out F low
[38]
Set digital out A high
[39]
Set digital out B high
[40]
Set digital out C high
[41]
Set digital out D high
[42]
Set digital out E high
[43]
Set digital out F high
[60]
Reset counter A
[61]
Reset counter B
[62]
Counter A (up)
[63]
Counter A (down)
[64]
Counter B (up)
[65]
Counter B (down)
Parameter 23-02 OFF Time
Table 1023: Parameter 23-02 OFF Time
23-02 OFF Time
Default value: Size related
Parameter type: Range, 0 - 0, Array [10]
Setup: 2 setups
Conversion index: 0
Data type: TimeOfDayWoDate
Change during operation: True
Sets the OFF time for the desired action.
N O T I C E
The drive has no back-up of the clock function. The set date/time resets to default (2000-01-01 00:00) after a power-down unless
a real-time clockmodule with back-up is installed. In parameter 0-79 Clock Fault, it is possible to program a warning if the clock has
not been set properly, for example after a power-down.
Parameter 23-03 OFF Action
Table 1024: Parameter 23-03 OFF Action
23-03 OFF Action
Default value: [1] No action
Parameter type: Option, Array [10]
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
AU275636650261en-000101 / 130R0334 | 553Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
