8. CONFIGURING THE ECL 2000
This section tells you how to begin using the ECL 2000 after it has been installed. The
ECL 2000 Installation Guide (ref. [2]) provides full details about the installation and
configuration of the ECL 2000.
8.1 Starting the ECL 2000 for the First Time
When the ECL 2000 is powered on, the controller dis-
plays the Danfoss logo.
The ECL 2000 is supplied with up to 17 different pre-programmed applications (see
below), accommodating a wide variety of plant configurations. Before the ECL 2000
is operational, you must select the application that matches your plant best. Once you
have selected an application, you have the possibility of customizing one or more
system parameters.
If the ECL 2000 has already been programmed with a pre-selected application, the
System Overview replaces the logo picture after a moment.
If no application is selected, the ECL 2000 automatically displays the Application 1
picture (see page 26), allowing you to select an application. See instructions on the
following pages.
8.2 ECL 2000 Types
Two different types of ECL 2000 are available. The table below summarizes the dif-
ferences between the two types (see also page 89).
Type 1 Type 2
Inputs
Pt 1000 7 7
Pt 1000, 0-10 V, pulse
or digital
24
Outputs
Relay (pump control) 3 3
3-point control (motor
valve control)
2 –
0-10 V (motor valve
control)
–3
