Basic set-up
Control parameters -
lines 4-7
26a
4 Proportional band, Xp
Circuit Setting range Factory setting
I / II 1 ... 250 K 80 / 80 K
Set the proportional band.
A higher value will result in a stable but slow
control of the ow temperature.
5 Integration time constant, Tn
Circuit Setting range Factory setting
I / II 5 ... 999 sec. 30 / 20 sec.
Set a high integration time constant to obtain a
slow but stable reaction to deviations.
A small integration constant will make the
controller react fast but with less stability
6 Running time of the motorized control valve
Circuit Setting range Factory setting
I / II 5 ... 250 sec. 35 / 15 sec.
Set the running time of the motorized control
valve according to the example. This is the time it
takes the controlled unit to move from fully closed
to fully open position.
How to calculate the running time of a motorized
control valve
The running time of the motorized control valve is calculated
using the following methods:
Seated valves
Running time = Valve stroke (mm) x actuator speed (sec. / mm)
Example: 5.0 mm x 15 sec. / mm = 75 sec.
Rotating valves
Running time = Turning degrees x actuator speed (sec. / degr.)
Example: 90 degrees x 2 = 180 sec.
