Relays and terminals on H6 enclosure
1
95
99
L1 91 / L2 92 / L3 93
U 96 / V 97 / W 98
03 02 01
06 05 04
2
3
4
130BB762.10
1 Mains
2 Motor
3 Ground
4 Relays
Illustration 3.4 H6 Enclosure
IP20, 380-480 V, 30-45 kW (40-60 HP)
IP20, 200-240 V, 15-18.5 kW (20-25 HP)
IP20, 525-600 V, 22-30 kW (30-40 HP)
Relays and terminals on H7 enclosure
1
2
3
4
130BB763.10
1 Mains
2 Relays
3 Ground
4 Motor
Illustration 3.5 H7 Enclosure
IP20, 380-480 V, 55-75 kW (70-100 HP)
IP20, 200-240 V, 22-30 kW (30-40 HP)
IP20, 525-600 V, 45-55 kW (60-70 HP)
Installation Quick Guide
12 Danfoss A/S © 08/2014 All rights reserved. MG18A602
