Danfoss FC 101 - Control Card, RS-485 Serial Communication; Control Card, 24 V DC Output; Relay Output; Control Card, 10 V DC Output 1)

6.4.9 Control Card, RS-485 Serial Communication
Terminal number 68 (P, TX+, RX+), 69 (N, TX-, RX-)
Terminal number 61 common for terminals 68 and 69
6.4.10 Control Card, 24 V DC Output
Terminal number 12
Maximum load 80 mA
6.4.11 Relay Output
Programmable relay output 2
Relay 01 and 02 01-03 (NC), 01-02 (NO), 04-06 (NC), 04-05 (NO)
Maximum terminal load (AC-1)
1)
on 01-02/04-05 (NO) (Resistive load) 250 V AC, 3 A
Maximum terminal load (AC-15)
1)
on 01-02/04-05 (NO) (Inductive load @ cosφ 0.4) 250 V AC, 0.2 A
Maximum terminal load (DC-1)
1)
on 01-02/04-05 (NO) (Resistive load) 30 V DC, 2 A
Maximum terminal load (DC-13)
1)
on 01-02/04-05 (NO) (Inductive load) 24 V DC, 0.1 A
Maximum terminal load (AC-1)
1)
on 01-03/04-06 (NC) (Resistive load) 250 V AC, 3 A
Maximum terminal load (AC-15)
1)
on 01-03/04-06 (NC) (Inductive load @ cosφ 0.4) 250 V AC, 0.2 A
Maximum terminal load (DC-1)
1)
on
01-03/04-06 (NC) (Resistive load)
30 V DC, 2 A
Minimum terminal load on 01-03 (NC), 01-02 (NO) 24 V DC 10 mA, 24 V AC
20 mA
Environment according to EN 60664-1 Overvoltage category III/pollution degree 2
1) IEC 60947 parts 4 and 5.
6.4.12
Control Card, 10 V DC Output
1)
Terminal number 50
Output voltage 10.5 V ±0.5 V
Maximum load 25 mA
1) All inputs, outputs, circuits, DC supplies and relay contacts are galvanically isolated from the supply voltage (PELV) and other
high-voltage terminals.
Specifications Quick Guide
52 Danfoss A/S © 08/2014 All rights reserved. MG18A602
