Danfoss FC 101 User Manual

Circuit breaker Fuse
UL Non UL UL Non UL
Bussmann Bussmann Bussmann Bussmann
Maximum
fuse
Power [kW/HP] Type RK5 Type RK1 Type J Type T Type G
3x200–240 V IP20
0.25 (0.33) FRS-R-10 KTN-R10 JKS-10 JJN-10 10
0.37 (0.5) FRS-R-10 KTN-R10 JKS-10 JJN-10 10
0.75 (1) FRS-R-10 KTN-R10 JKS-10 JJN-10 10
1.5 (2) FRS-R-10 KTN-R10 JKS-10 JJN-10 10
2.2 (3) FRS-R-15 KTN-R15 JKS-15 JJN-15 16
3.7 (5) FRS-R-25 KTN-R25 JKS-25 JJN-25 25
5.5 (7.5) FRS-R-50 KTN-R50 JKS-50 JJN-50 50
7.5 (10) FRS-R-50 KTN-R50 JKS-50 JJN-50 50
11 (15) FRS-R-80 KTN-R80 JKS-80 JJN-80 65
15 (20)
Cutler-Hammer
EGE3100FFG
Moeller NZMB1-
A125
FRS-R-100 KTN-R100 JKS-100 JJN-100 125
18.5 (25) FRS-R-100 KTN-R100 JKS-100 JJN-100 125
22 (30)
Cutler-Hammer
JGE3150FFG
Moeller NZMB1-
A160
FRS-R-150 KTN-R150 JKS-150 JJN-150 160
30 (40) FRS-R-150 KTN-R150 JKS-150 JJN-150 160
37 (50)
Cutler-Hammer
JGE3200FFG
Moeller NZMB1-
A200
FRS-R-200 KTN-R200 JKS-200 JJN-200 200
45 (60) FRS-R-200 KTN-R200 JKS-200 JJN-200 200
3x380–480 V IP20
0.37 (0.5) FRS-R-10 KTS-R10 JKS-10 JJS-10 10
0.75 (1) FRS-R-10 KTS-R10 JKS-10 JJS-10 10
1.5 (2) FRS-R-10 KTS-R10 JKS-10 JJS-10 10
2.2 (3) FRS-R-15 KTS-R15 JKS-15 JJS-15 16
3 (4) FRS-R-15 KTS-R15 JKS-15 JJS-15 16
4 (5) FRS-R-15 KTS-R15 JKS-15 JJS-15 16
5.5 (7.5) FRS-R-25 KTS-R25 JKS-25 JJS-25 25
7.5 (10) FRS-R-25 KTS-R25 JKS-25 JJS-25 25
11 (15) FRS-R-50 KTS-R50 JKS-50 JJS-50 50
15 (20) FRS-R-50 KTS-R50 JKS-50 JJS-50 50
18.5 (25) FRS-R-80 KTS-R80 JKS-80 JJS-80 65
22 (30) FRS-R-80 KTS-R80 JKS-80 JJS-80 65
30 (40)
Cutler-Hammer
EGE3125FFG
Moeller NZMB1-
A125
FRS-R-125 KTS-R125 JKS-R125 JJS-R125 80
37 (50) FRS-R-125 KTS-R125 JKS-R125 JJS-R125 100
45 (60) FRS-R-125 KTS-R125 JKS-R125 JJS-R125 125
55 (70)
Cutler-Hammer
JGE3200FFG
Moeller NZMB1-
A200
FRS-R-200 KTS-R200 JKS-R200 JJS-R200 150
75 (100) FRS-R-200 KTS-R200 JKS-R200 JJS-R200 200
90 (125)
Cutler-Hammer
JGE3250FFG
Moeller NZMB2-
A250
FRS-R-250 KTS-R250 JKS-R250 JJS-R250 250
3x525–600 V IP20
2.2 (3) FRS-R-20 KTS-R20 JKS-20 JJS-20 20
3 (4) FRS-R-20 KTS-R20 JKS-20 JJS-20 20
3.7 (5) FRS-R-20 KTS-R20 JKS-20 JJS-20 20
5.5 (7.5) FRS-R-20 KTS-R20 JKS-20 JJS-20 20
7.5 (10) FRS-R-20 KTS-R20 JKS-20 JJS-20 30
11 (15) FRS-R-30 KTS-R30 JKS-30 JJS-30 35
15 (20) FRS-R-30 KTS-R30 JKS-30 JJS-30 35
18.5 (25)
Cutler-Hammer
EGE3080FFG
Cutler-Hammer
EGE3080FFG
FRS-R-80 KTN-R80 JKS-80 JJS-80 80
22 (30) FRS-R-80 KTN-R80 JKS-80 JJS-80 80
30 (40) FRS-R-80 KTN-R80
JKS-80 JJS-80
80
Installation Quick Guide
18 Danfoss A/S © 08/2014 All rights reserved. MG18A602
