6.1.3 Compressor Pack
P
0
130BA807.10
Figure 6.4 P
0
Pressure Transmitter
FC 103
Supply
1 2
AKS33
12 18 27 20 55 54 U V W
130BA808.11
Figure 6.5 How to Connect the FC 103 and AKS33 for Closed-
loop Applications
NOTICE!
To find out which parameters are relevant, run the
SmartStart.
Application Set-up Examples Instruction Manual
