Danfoss FC 103 - Page 63

8.8.1 CE Compliance
200–240 V
Enclosure
type
Power (hp [kW]) Recommended
fuse size
Recommended
max. fuse size
Recommended circuit
breaker (Moeller)
Max. trip level [A]
A2 1.5–3 [1.1–2.2] gG-10 (1.5–2 [1.1–1.5])
gG-16 (3 [2.2])
gG-25 PKZM0-25 25
A3 4–5 [3.0–3.7] gG-16 (4 [3])
gG-20 (5 [3.7])
gG-32 PKZM0-25 25
B3 7.5–15 [5.5–11] gG-25 (7.5–10 [5.5–7.5])
gG-32 (15 [11])
gG-63 PKZM4-50 50
B4 20–24 [15–18] gG-50 (20 [15])
gG-63 (25 [18])
gG-125 NZMB1-A100 3.94 [100]
C3 30–40 [22–30] gG-80 (30 [22])
aR-125 (40 [30])
gG-150 (22)
aR-160 (30)
NZMB2-A200 150
C4 50–60 [37–45] aR-160 (50 [37])
aR-200 (60 [45])
aR-200 (50 [37])
aR-250 (60 [45])
NZMB2-A250 250
A4 1.5–3 [1.1–2.2] gG-10 (1.5–2 [1.1–1.5])
gG-16 (3 [2.2])
gG-32 PKZM0-25 25
A5 0.34–5 [0.25-3.7] gG-10 (0.34–2 [0.25–1.5])
gG-16 (3–4 [2.2–3])
gG-20 (5 [3.7])
gG-32 PKZM0-25 25
B1 7.5–15 [5.5–11] gG-25 (7.5 [5.5])
gG-32 (10–15 [7.5–11])
gG-80 PKZM4-63 63
B2 15 gG-50 gG-100 NZMB1-A100 100
C1 24–40 [18–30] gG-63 (25 [18.5])
gG-80 (30 [22])
gG-100 (40 [30])
gG-160 (25–30 [18.5–22])
aR-160 (40 [30])
NZMB2-A200 160
C2 50–60 [37–45] aR-160 (50 [37])
aR-200 (60 [45])
aR-200 (50 [37])
aR-250 (60 [45])
NZMB2-A250 250
Table 8.8 200–240 V, Enclosure Types A, B and C
