380–480 V
Enclosure
type
Power (hp [kW]) Recommended
fuse size
Recommended
max. fuse size
Recommended circuit
breaker (Moeller)
Max. trip level [A]
A2 1.5–5 [1.1–4.0] gG-10 (1.5–4 [1.1–3])
gG-16 (5 [4])
gG-25 PKZM0-25 25
A3 7.5–10 [5.5–7.5] gG-16 gG-32 PKZM0-25 25
B3 15–24 [11–18] gG-40 gG-63 PKZM4-50 50
B4 30–50 [22–37] gG-50 (30 [22])
gG-63 (40 [30])
gG-80 (50 [37])
gG-125 NZMB1-A100 3.94 [100]
C3 60–75 [45–55] gG-100 (60 [45])
gG-160 (75 [55])
gG-150 (60 [45])
gG-160 (75 [55])
NZMB2-A200 150
C4 100–125 [75–90] aR-200 (100 [75])
aR-250 (125 [90])
aR-250 NZMB2-A250 250
A4 1.5–5 [1.1–4] gG-10 (1.5–4 [1.1–3])
gG-16 (5 [4])
gG-32 PKZM0-25 25
A5 1.5–10 [1.1–7.5] gG-10 (1.5–4 [1.1–3])
gG-16 (5–10 [4–7.5])
gG-32 PKZM0-25 25
B1 15–25 [11–18.5] gG-40 gG-80 PKZM4-63 63
B2 30–40 [22–30] gG-50 (30 [22])
gG-63 (40 [30])
gG-100 NZMB1-A100 100
C1 50–75 [37–55] gG-80 (50 [37])
gG-100 (60 [45])
gG-160 (75 [55])
gG-160 NZMB2-A200 160
C2 100–125 [75–90] aR-200 (100 [75])
aR-250 (125 [90])
aR-250 NZMB2-A250 250
Table 8.9 380–480 V, Enclosure Types A, B and C
