525–600 V
Enclosure
type
Power (hp [kW]) Recommended
fuse size
Recommended
max. fuse size
Recommended circuit
breaker (Moeller)
Max. trip level [A]
A3 7.5–10 [5.5–7.5] gG-10 (7.5 [5.5])
gG-16 (10 [7.5])
gG-32 PKZM0-25 25
B3 15–24 [11–18] gG-25 (15 [11])
gG-32 (20–25 [15–18])
gG-63 PKZM4-50 50
B4 30–50 [22–37] gG-40 (30 [22])
gG-50 (40 [30])
gG-63 (50 [37])
gG-125 NZMB1-A100 100
C3 60–75 [45–55] gG-63 (60 [45])
gG-100 (75 [55])
gG-150 NZMB2-A200 150
C4 100–125 [75–90] aR-160 (100 [75])
aR-200 (125 [90])
aR-250 NZMB2-A250 250
A5 1.5–10 [1.1–7.5] gG-10 (1.5–7.5 [1.1–5.5])
gG-16 (10 [7.5])
gG-32 PKZM0-25 25
B1 15–24 [11–18] gG-25 (15 [11])
gG-32 (20 [15])
gG-40 (25 [18.5])
gG-80 PKZM4-63 63
B2 30–40 [22–30] gG-50 (30 [22])
gG-63 (40 [30])
gG-100 NZMB1-A100 100
C1 50–75 [37–55] gG-63 (50 [37])
gG-100 (60 [45])
aR-160 (75 [55])
gG-160 (50–60 [37–45])
aR-250 (75 [55])
NZMB2-A200 160
C2 100–125 [75–90] aR-200 (100–125 [75–90]) aR-250 NZMB2-A250 250
Table 8.10 525–600 V, Enclosure Types A, B and C
