12-13 Link Speed
Option: Function:
Forces the link speed for each port at 10 or 100
Mbps. If par. 12-12 is set to ON, this parameter is
read-only and displays the actual link speed.
“None” is displayed if no link is present.
[0]
*
None
[1] 10 Mbps
[2] 100 Mbps
12-14 Link Duplex
Option: Function:
Forces the duplex for each port to full or half
duplex. If par. 12-12 is set to ON, this parameter
is read-only.
[0] Half duplex
[1]
*
Full duplex
3.13.3 12-2* Process Data
12-20 Control Instance
Range: Function:
[None, 20, 21, 100,
101, 103]
Read only. Displays the originator-to-
target connection point. If no CIP
connection is present, “None” is displayed.
12-21 Process Data Config Write
Range: Function:
[[0–9] PCD read 0–9] Configuration of readable process data.
NOTE!
For configuration of 2-word (32-bit) parameter read/write,
use 2 consecutive arrays in par. 12-21 and 12-22.
12-22 Process Data Config Read
Range: Function:
[[0–9] PCD read 0–9] Configuration of readable process data.
12-28 Store Data Values
Option: Function:
This parameter activates a function that stores all
parameter values in the non-volatile memory
(EEPROM) thus retaining parameter values at
power-down.
The parameter returns to “Off”.
[0]
*
Off The store function is inactive.
[1] Store all
set-ups
All parameter value will be stored in the non-
volatile memory in all four set-ups.
12-29 Store Always
Option: Function:
Activates function that will always store received
parameter data in non-volatile memory (EEPROM).
[0]
*
Off
[1] On
3.13.4 12-3* EtherNet/IP
12-30 Warning Parameter
Range: Function:
[0000–
FFFF hex]
Read only. Displays the EtherNet/IP specific 16-bit
status word.
Bit Description
0Owned
1Not used
2Configured
3Not used
4Not used
5Not used
6Not used
7Not used
8 Minor recoverable fault
9 Minor unrecoverable fault
10 Major recoverable fault
11 Major unrecoverable fault
12 Not used
13 Not used
14 Not used
15 Not used
12-31 Net Reference
Option: Function:
Read only. Displays the reference source in Instance
21/71.
[0]
*
Off Reference from the network is not active.
[1] On Reference from the network is active.
12-32 Net Control
Option: Function:
Read only. Displays the control source in Instance 21/71.
[0]
*
Off Control via the network is not active.
[1] On Control via the network is active
12-33 CIP Revision
Option: Function:
Read only. Displays the CIP version of
the option software.
[0] Major version (00–99)
[1] Minor version (00–99)
Parameter Descriptions FC 300 Programming Guide
MG.33.MA.22 - VLT
®
is a registered Danfoss trademark 3-103
3
