0-30 Unit for User-defined Readout
Option: Function:
It is possible to program a value to be shown
in the display of the LCP. The value will have a
linear, squared or cubed relation to speed.
This relation will depend on the unit selected
(see table above). The actual calculated value
can be read in 16-09 Custom Readout, and/or
shown in the display by selecting Custom
Readout [16-09] in 0-20 Display Line 1.1 Small
to 0-24 Display Line 3 Large.
[0]
*
None
[1] %
[5] PPM
[10] min
[11] RPM
[12] PULSE/s
[20] liter / sec.
[21] liter / min
[22] liter / hr.
[23] m / sec.
[24] m/min
[25] m / hr.
[30] kg / sec.
[31] kg/min
[32] kg / hr.
[33] ton / min
[34] ton / hr.
[40] m / sec.
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal / sec.
[122] gal/min
[123] gal / hr.
[124] CFM
[125] ft/s
[126] ft/min
[127] ft/h
[130] lbs / sec.
[131] lbs / min.
[132] lbs / hr.
[140] ft/s
[141] ft/min
[145] ft
0-30 Unit for User-defined Readout
Option: Function:
[160] °F
[170] psi
[171] lb/inR
[172] in. wtr. gage
[173] ft WG
[180] HP
0-31 Min Value of User-defined Readout
Range: Function:
0.00 CustomRea-
doutUnit
*
[Application
dependant]
This parameter sets the min.
value of the custom defined
readout (occurs at zero speed).
Only possible to set different
from 0 is when selecting a
linear unit in 0-30 Unit for User-
defined Readout. For quadratic
and cubic units, the minimum
value will be 0.
0-32 Custom Readout Max Value
Range: Function:
100.00 Custom-
ReadoutUnit
*
[Application
dependant]
This parameter sets the max
value to be shown when the
speed of the motor has
reached the set value for
4-13 Motor Speed High Limit
[RPM] or 4-14 Motor Speed High
Limit [Hz] (depends on setting
in 0-02 Motor Speed Unit).
0-37 Display Text 1
Range: Function:
0
*
[0 - 0 ] Enter a text which can be viewed in the graphical
display by selecting Display Text 1 [37] in par. 0-20,
0-21, 0-22, 0-23 or 0-24.
0-38 Display Text 2
Range: Function:
0
*
[0 - 0 ] Enter a text which can be viewed in the graphical
display by selecting Display Text 2 [38] in par. 0-20,
0-21, 0-22, 0-23 or 0-24.
0-39 Display Text 3
Range: Function:
0
*
[0 - 0 ] Enter a text which can be viewed in the graphical
display by selecting Display Text 3 [39] in par. 0-20,
0-21, 0-22, 0-23 or 0-24.
Parameter Descriptions FC 300 Programming Guide
MG.33.MA.22 - VLT
®
is a registered Danfoss trademark 3-9
