Par. No. #
Parameter description Default value 4-set-up FC 302
only
Change during
operation
Conver-
sion index
Type
5-0* Digital I/O mode 5-00 Digital I/O Mode [0] PNP All set-ups FALSE - Uint8 5-01 Terminal 27 Mode [0] Input All set-ups TRUE - Uint8
5-02
Terminal 29 Mode [0] Input All set-ups x TRUE - Uint8
5-1* Digital Inputs 5-10 Terminal 18 Digital Input null All set-ups TRUE - Uint8 5-11 Terminal 19 Digital Input null All set-ups TRUE - Uint8
5-12 Terminal 27 Digital Input null All set-ups TRUE - Uint8
5-13 Terminal 29 Digital Input null All set-ups x TRUE - Uint8
5-14 Terminal 32 Digital Input [0] No operation All set-ups TRUE - Uint8
5-15 Terminal 33 Digital Input [0] No operation All set-ups TRUE - Uint8
5-16 Terminal X30/2 Digital Input [0] No operation All set-ups TRUE - Uint8
5-17 Terminal X30/3 Digital Input [0] No operation All set-ups TRUE - Uint8
5-18 Terminal X30/4 Digital Input [0] No operation All set-ups TRUE - Uint8
5-19 Terminal 37 Safe Stop [1] Safe Stop Alarm 1 set-up x TRUE - Uint8 5-3* Digital Outputs 5-30 Terminal 27 Digital Output null All set-ups TRUE - Uint8 5-31 Terminal 29 digital Output null All set-ups x TRUE - Uint8 5-32 Term X30/6 Digi Out (MCB 101) null All set-ups TRUE - Uint8
5-33
Term X30/7 Digi Out (MCB 101) null All set-ups TRUE - Uint8
5-4* Relays 5-40 Function Relay null All set-ups TRUE - Uint8 5-41 On Delay, Relay 0.01 s All set-ups TRUE -2 Uint16
5-42
Off Delay, Relay 0.01 s All set-ups TRUE -2 Uint16
5-5* Pulse Input 5-50 Term. 29 Low Frequency 100 Hz All set-ups x TRUE 0 Uint32 5-51 Term. 29 High Frequency 100 Hz All set-ups x TRUE 0 Uint32
5-52 Term. 29 Low Ref./Feedb. Value 0.000 ReferenceFeedbackUnit All set-ups x TRUE -3 Int32
5-53 Term. 29 High Ref./Feedb. Value ExpressionLimit All set-ups x TRUE -3 Int32
5-54 Pulse Filter Time Constant #29 100 ms All set-ups x FALSE -3 Uint16
5-55 Term. 33 Low Frequency 100 Hz All set-ups TRUE 0 Uint32
5-56 Term. 33 High Frequency 100 Hz All set-ups TRUE 0 Uint32
5-57 Term. 33 Low Ref./Feedb. Value 0.000 ReferenceFeedbackUnit All set-ups TRUE -3 Int32
5-58 Term. 33 High Ref./Feedb. Value ExpressionLimit All set-ups TRUE -3 Int32
5-59 Pulse Filter Time Constant #33 100 ms All set-ups FALSE -3 Uint16
4.3.6. 5-** Digital In/Out
