Danfoss FC 301

Par. No. #
Parameter description Default value 4-set-up FC 302
only
Change during
operation
Conver-
sion index
Type
17-1* Inc. Enc. Interface 17-10 Signal Type [1] TTL (5V, RS4222) All set-ups FALSE - Uint8 17-11 Resolution (PPR) 1024 N/A All set-ups FALSE 0 Uint16 17-2* Abs. Enc. Interface 17-20 Protocol Selection [0] None All set-ups FALSE - Uint8 17-21 Resolution (Positions/Rev) ExpressionLimit All set-ups FALSE 0 Uint32 17-24 SSI Data Length 13 N/A All set-ups FALSE 0 Uint8
17-25 Clock Rate ExpressionLimitAll set-ups FALSE3Uint16
17-26 SSI Data Format [0] Gray code All set-ups FALSE - Uint8
17-34
HIPERFACE Baud rate [4] 9600 All set-ups FALSE - Uint8
17-5* Resolver Interface 17-50 Poles 2 N/A 1 set-up FALSE 0 Uint8 17-51 Input Voltage 7.0 V 1 set-up FALSE -1 Uint8
17-52 Input Frequency 10.0 kHz 1 set-up FALSE 2 Uint8
17-53 Transformation Ratio 0.5 N/A 1 set-up FALSE -1 Uint8
17-59
Resolver Interface [0] Disabled All set-ups FALSE - Uint8
17-6* Monitoring and App. 17-60 Feedback Direction [0] Clockwise All set-ups FALSE - Uint8 17-61 Feedback Signal Monitoring [1] Warning All set-ups TRUE - Uint8
4.3.16. 17-** Motor Feedb.Option
VLT
®
AutomationDrive FC 300 Instruction
Manual
4. How to Program
MG.33.A9.22 - VLT is a registered Danfoss trademark 75
4
