Parameters
Range/number
Function of settings/value Factory setting Parameter No.
Language 6 English Parameter 001
Local/remote control 2 Remote control Parameter 002
Local reference 000.000 Parameter 003
Active Setup 4 Setup 1 Parameter 004
Programming Setup 4 Active setup Parameter 005
Copying of Setups 4 No copying Parameter 006
LCP copy 4 No copying Parameter 007
Display scaling of motor frequency 100 Parameter 008
Display line 2 24 Frequency [Hz] Parameter 009
Display line 1.1 Reference [%] Parameter 010
Display line 1.2 Motor current [A] Parameter 011
Display line 1.3 Power [kW] Parameter 012
Local control/configaration 5 LCP digital control/par. 100 Parameter 013
Local stop 2 Possible Parameter 014
Local jog 2 Not possible Parameter 015
Local reversing 2 Not possible Parameter 016
Local reset of trip 2 Possible Parameter 017
Lock for data change 2 Not locked Parameter 018
Operating state at power up, local c. 3 Forced stop, use saved ref. Parameter 019
Configuration 2 Speed, open loop mode Parameter 100
Torque characteristics 4 Constant torque Parameter 101
Motor power XX.XX kW - dep. on unit Parameter 102
Motor voltage XX.XX V - dep. on unit Parameter 103
Motor frequency XX.X Hz - dep. on unit Parameter 104
Motor current XX.XX A - dep. on unit Parameter 105
Rated motor speed XX rpm - dep. on unit Parameter 106
DC braking time 0.0 (off) - 60.0 sec. 10.0 sec. Parameter 126
DC brake cut-in frequency 0.0 Hz - f
MAX
0.0 Hz Parameter 127
Motor thermal protection 2 Disable Parameter 128
DC braking voltage 0 - 100 % 0 % Parameter 132
Start voltage 0.00 - 100.00 V Motor dependent Parameter 133
Start compensation 0.0 - 300.0 % 100.0 % Parameter 134
U/f ratio 0.00 - 20.00 V/Hz Motor dependent Parameter 135
Slip compensation -500.0 - +500.0 % 100.0 % Parameter 136
DC holding voltage 0 - 100 % 0 % Parameter 137
Brake cut out frequency 0.5 - 132 Hz 3.0 Hz Parameter 138
Brake cut in frequency 0.5 - 132 Hz 3.0 Hz Parameter 139
Rotation direction 3 Only clockwise 0 - 132 Hz Parameter 200
Min. output frequency (f
MIN
) 0.0 Hz - f
MAX
0.0 Hz Parameter 201
Max. output frequency (f
MAX
)f
MIN -
f
RANGE
f
RANGE
(132 Hz) Parameter 202
Reference/feedback range Min. - max./-max.- +max. Min. - Max. Parameter 203
Minimum reference -100,000.000 - Ref
MAX
0.000 Parameter 204
Maximum reference Ref
MIN
- 100,000.000 50.000 Parameter 205
Ramp-up time 1 0.05 - 3600.00 sec. 3.00 sec. Parameter 207
Ramp-down time 1 0.05 - 3600.00 sec. 3.00 sec. Parameter 208
Jog ramp time 0.05 - 3600.00 sec. 3.00 sec. Parameter 211
Quick stop ramp-down time 0.05 - 3600.00 sec. 3.00 sec. Parameter 212
Jog frequency 0 Hz - f
MAX
10.0 Hz Parameter 213
Reference function 2 Sum Parameter 214
Parameters for programming, controlling, and monitoring the FCM 300 via serial communication or PC.
References and limitsReferences and limits
References and limitsReferences and limits
References and limits
Load and motorLoad and motor
Load and motorLoad and motor
Load and motor
Operation and displayOperation and display
Operation and displayOperation and display
Operation and display
■
Standard Parameter Setting
19-2
