■ Product range VLT
®
DriveMotor FCM 300 Series,
2/4 poled motors
FCM 355-P-T4-ST-S55-R2-0213T-4-1-B03-213-T-00
This means that the ordered FCM300 is an
FCM355 7,5 HP, three-phase mains voltage of
380 - 480V +/- 10%,
T4 and for process
application
P. The inverter is a standard version
for remote control
ST in a NEMA 12/IP55
enclosure
S55 with integrated RFI filter, class B1
R2. The motor frame size and version is 213T
which is a foot mounted motor
0213T. The motor
has 4 poles
4 and is cooled by the shaft-mounted
fan
1. The motor is a foot mounted motor B03
and the frame is 213. The inverter box is
mounted on the top of the motor
T and no drain
hole is placed
00.
As an example the above motor with D flange,
inverter on the right side, drain hole position
between feet
FCM355-P-T4-ST-S55-R2-0213T-4-1-B05-213-
R-D1
If you wish to place your order by using the type
code directly, please use the codes given in
parenthesis on the left-hand side of the ordering
forms. The code sequence in the type code is
stated at the top of each part of the form
(character number).
The ordering form for the basic unit must always
be completed. When the type code is written,
always state the characters of the basic string (1-
30).
Together with the order confirmation the
customer receives an 8-figure code number to be
used when reordering.
Type
Motor
Mains supply
output
FCM 305FCM 305
FCM 305FCM 305
FCM 305 0.75 HP
FCM 307FCM 307
FCM 307FCM 307
FCM 307 1.0 HP
FCM 311FCM 311
FCM 311FCM 311
FCM 311 1.5 HP
FCM 315FCM 315
FCM 315FCM 315
FCM 315 2.0 HP
FCM 322FCM 322
FCM 322FCM 322
FCM 322 3.0 HP
3 phase 380-480 V
FCFC
FCFC
FC
M 330M 330
M 330M 330
M 330 4.0 HP
FCM 340FCM 340
FCM 340FCM 340
FCM 340 5.0 HP
FCM 35FCM 35
FCM 35FCM 35
FCM 35
55
55
5 7.5 HP
FCM 37FCM 37
FCM 37FCM 37
FCM 37
55
55
5 10.0 HP
Each type in the product range is available in
different versions.
Inverter versions
Drive control:
-ST: Standard version
- SP: Version for PROFIBUS
RFI filter:
Inverter with integrated RFI filter, class A1 (industrial)
or class B1 (domestic).
Cooling:
- TEFV: Motor cooled by a shaft mounted fan (IC
411)
- FV: Motor cooled by an independent fan (IC 416)
(Not UL)
Mounting versions
- Foot mounting (B3)
- Flange mounting (B5)
- Face mounting (B14)
- Foot + flange mounting (B35)
- Foot + face mounting (B34)
See chapter 6.
Inverter box position: Top, right side or left side.
Drainhole (+ position): None, between feet, opposite
feet, vertical drive end, vertical non-drive end, 90°
right of feet, 90° left of feet.
■■
■■
■ NEMA Ordering
Take a copy of the ordering forms on page 4-8. Fill
in and post or fax your order to the nearest branch
office of the Danfoss sales organisation. On the
basis of your order, the FCM 300 Series motor is
given a type code, which may look as follows:
4-4
Ordering
