FCM 300 Series
MG.03.B6.2G - VLT is a registered Danfoss trademark
Handling and lifting of VLT
®
DriveMotors (FCM 300
units) must only be undertaken by qualified personnel.
Full product documentation and operating instructions
must be available together with tools and equipment
necessary for safe working practice. Eyebolts and/or
lifting points supplied with the FCM 300 are designed
to support only the weight of the FCM 300, not the
weight of the FCM 300 and any auxiliary equipment
attached to it. Be absolutely sure that cranes, jacks,
slings and lifting beams are capable of carrying the
weight of equipment to be lifted.
Where an eyebolt is provided with the motor,
■ Handling the FCM 300
this should be screwed down until its shoulder is
firmly against seated the face of the stator frame to be
lifted.
FCM type approx. weight (kg.) lbs
FCM 305 11 24,3
FCM 307 13 28,7
FCM 311 17 37,5
FCM 315 20 44,1
FCM 322 26 57,3
FCM 330 28 61,7
FCM 340 37 81,6
FCM 355 56 123,5
FCM 375 61 134,5
■■
■■
■
Bearings
To avoid static indention, the storage area should be
vibration free. Where exposure to some vibration is
unavoidable, the shaft should be locked. Bearings
may be fitted with a shaft locking device which
should be kept in place during storage.
Shafts should be rotated by hand, one quarter of a
revolution, at weekly intervals.
Lubrication
FCM Lubrication Temperature
type range
305 - 375 Esso unirex N3 -10 + 140
o
C/
-14 + 284
o
F
Bearing life
Maximum hours bearing life (Lna) expected at 80
o
C/176
o
F bearing temp. x 10
3
hours.
FCM 3600 rpm 3000 rpm 1800 rpm 1500 rpm
Horiz. Vert. Horiz. Vert. Horiz. Vert. Horiz.Vert.
305-315 20 20 22 22 30 30 32 32
322-340 22 22 26 26 33 33 35 35
355-375 22 22 26 26 33 33 35 35
Lna bearing life is the adjusted, L10 life rating, taking account of: -Reliability -Material improvement -Lubrication conditions.
Standard Bearing references and oil seals
FCM Mounting Poles (2/4) Bearings Oil seals - Bore x O/D x width in mm
Drive end Non-drive end Drive end Non-drive end
305-307 All All 6204 2Z 6202 2Z 20 x 30 x 7 15 x 24 x 5
311-315 All All 6205 2Z 6203 2Z 25 x 35 x 7 17 x 28 x 6
322-330 All All 6206 2Z 6205 2Z 30 x 42 x 7 25 x 37 x 7
340 All All 6206 2Z 6205 2Z 30 x 42 x 7 25 x 37 x 7
355-375 All All 6208 2Z 6305 2Z 40 x 52 x 7 25 x 37 x 7
■■
■■
■
Output shafts
Output shafts are produced from 35/40 Ton
(460/540 MN/m
2
) tensile steel. Drive end shafts are
provided with a tapped hole to DIN 332 Form D and
a closed profile keyway as standard.
Balance
All motors are dynamically balanced, to ISO 2373
with key convention to IEC 34-14.
InertiaInertia
InertiaInertia
Inertia
FCM J [kgm
2
]*
2 pole 4 pole
305 0.0015 0.0019
307 0.0015 0.0027
311 0.0024 0.0035
315 0.0024 0.0047
322 0.006 0.009
330 0.007 0.010
340 0.008 0.016
355 0.017 0.027
375 0.020 0.032
Installation
* 1 kgm
2
= 23.73036 lbft
2
NOTE!
Ball and roller bearings are shipped from the factory
fully charged with grease. Sealed bearings have
sufficient grease for at least two years of continuous
operation in normal ambient temperatures (see
General Specifications).
6-5
