Danfoss H1B 060 Service Manual

H1 system schematic
System schematic H1 pump and H1 motor with EDC
P003 424
min.max.
L2 NMA
A
B
M5
MB
M4
L1
B
R1
R2
M4
M5
M14 M6 1 2
M3 L1 L2 MA
A
C2 C1
S
F00B F00A
L3 L4
CW
MB
max. 3 bar
[43.5 psi]
n
The schematic above shows the function of a hydrostatic transmission using an H1 axial variable displacement pump with electric
proportional displacement control (EDC) and an H1 bent axis variable displacement motor with electric proportional control (L*) and
integrated loop flushing device.
Service Manual
H1 Bent Axis Motors, Size 060/080/110/160/210/250 cm3
H1 general information
12 |
©
Danfoss | August 2018 AX00000025en-US0504
