1. Lubricate and install spring (F0040) and spring seat (F0030) into servo.
2. Install a new gasket (C0130).
3. Position control on motor.
4. Install four cap screws (C0110 and/or C0120).
C0110 and C0120 Wrench Size
Screw Control Torque Internal Hex
Wrench
C0110
Electric / Hydraulic proportional 37 N•m
[27 lbf•ft]
6 mm
C0110, C0120
Two-position 115 N•m
[85 lbf•ft]
10 mm
Service Manual
H1 Bent Axis Motors, Size 060/080/110/160/210/250 cm3
Minor repair
©
Danfoss | August 2018 AX00000025en-US0504 | 45
