13. Lubricate and install new O-ring (B0028) onto solenoid.
14. Install coil nut (B0027) and torque to 3.5 N•m [2.6 lbf•ft] using a 26 mm 12-point socket.
Do not over torque.
15. Install new O-ring (B0029) and plastic cap (B0040) to solenoid.
Service Manual
H1 Bent Axis Motors, Size 060/080/110/160/210/250 cm3
Minor repair
