1. If previously removed, install orifices (E00T3 and E00T2) using a 3 mm internal hex wrench. Torque to
6 N•m [4 lbf•ft].
2. Lubricate and install spools (C0020) and (C0070) and springs (C0080) and (C0030).
3. Lubricate and install O-ring (M223). Install pressure compensator adjusting plug (C0090). Torque to
25 N•m [18 lbf•ft].
4. Lubricate and install two O-rings (C0050A). Using a 1/4 inch internal hex wrench, install plugs (C0050).
Torque to 25 N•m [19 lbf•ft].
5. Lubricate and install four O-rings (C0060A). Using a 1/8 inch internal hex wrench, install plugs
(C0060). Torque to 8 N•m [6 lbf•ft].
6. Lubricate and install O-rings (B0034).
7. Install solenoids (B0032) using a 17 mm open-end wrench on the flats provided. Torque to 25 N•m [19
lbf•ft] .
8. Lubricate and install new O-rings (B0024) on solenoids.
9. Install coils (B0022).
10. Lubricate and install new O-rings (B0028).
11. Install coil nuts (B0026) using a 26 mm 12-point socket. Torque to 3.5 N•m [2.6 lbf•ft].
Do not over torque.
Service Manual
H1 Bent Axis Motors, Size 060/080/110/160/210/250 cm3
Minor repair
©
Danfoss | August 2018 AX00000025en-US0504 | 53
