User Guide PFM 1000
VU.E2.G1.02 | 19© Danfoss | 2019.02
Specifications
Nominal pressure range
1)
1,000kPa or 2,000 kPa Power Consumption 20 mA Bluetooth use
Max. Overpressure 120% of nominal pressure Operating time 45 hours Max.
Linearity and hysteresis error
0.15% from nominal pressure
range
Zeroing of the pressure
measurement
Mechanical with hydraulic
bypass
Temperature error
0.25% from nominal pressure
range
Water Resistance IP65
Medium temperature
2)
-5 to 90°C Calibration Validity 24 months
Ambient temperature -5 to 50°C Dimensions (l x w x d) 180x80x52 mm
Storage temperature -5 to 50°C Weight 420 g
Wireless data transfer Bluetooth Low Energy 5.0
Power supply
AAA Alkaline batteries or
NiMH rechargeable batteries
1) Optional
2) Measured at the end of measuring hoses, length 1.5m, Hot water flows through PFM 1000 hydraulic parts during Pressure zero
procedure. Maximum time duration of zeroing when temperature of the medium exceeds 50°C is 10 seconds.
