Page #11 background imageLoading...
Page #11 background image
Specifications
Description Units Minimum Maximum Comment
Allowed voltage at pin Vdc 0 36
Measured resistance Ω 0 10,000
Minimum discernable current mA 0 0.1
Maximum discernable current mA 25.3 27
Precision µA 6
Worst case error µA 868 Over the full temperature range
-40°C to 85°C (-40°F to 185°F)
Input impedance Ω 198.6 202.6
Maximum over-current protection time at start up (current ≥ 24 mA) ms 100
Recover time after over-current protection s 5.4
Maximum discernable voltage (high range) Vdc 25.3
Minimum discernable voltage (high range) mV 0 130
Precision (high range) mV 9
Worst case error (high range) Vdc 1.16 Over the full temperature range
-40°C to 85°C (-40°F to 185°F)
Maximum discernable voltage (middle range) Vdc 5.13 5.38
Minimum discernable voltage (middle range) mV 0 20
Precision (middle range) mV 1.3
Worst case error mV 120 Over the full temperature range
-40°C to 85°C (-40°F to 185°F)
Input impedance (pulled to 5 Vdc or ground high range) 13.0 13.4
Input impedance (pulled to 2.5 Vdc high range) 6.9 7.1
Input impedance (no pull ups high range) 108 112
Input impedance (pulled to 5 Vdc or ground middle range) 13.9 14.3
Input impedance (pulled to 2.5 Vdc middle range) 7.2 7.4
Input impedance (no pull ups middle range) 230 236
Technical Information
PLUS+1 SC0XX-1XX Controller Family
Inputs
©
Danfoss | June 2016 L1415500 | BC00000235en-US0201 | 11
