Specifications
Description Minimum Maximum Comment
EEPROM write/erase cycles 1 million Minimum valid over entire operating temperature
range.
EEPROM used in PLUS+1
®
controllers is rated for one million read/write cycles per sector. Sector size is 32
bits. When a value is written to EEPROM, all 32 bits in a particular sector are always written, regardless of
the size of the size of the saved value. If the value being saved in a sector is less than 32 bits (such as U8,
S16, BOLL) adjacent bits in the same EEPROM sector are rewritten with their previous value. The
implication of this memory property is that if two values are being written to the same memory sector,
the useful life of the sector is determined by the value being written most frequently. If that value
exceeds 1 million read/write cycles, all values in the sector may be compromised if the useful life is
exceeded.
Environmental testing criteria
General product ratings
Description Units Minimum Maximum Comment
Operating temperature ˚C [˚F] -40 [-40] 85 [185]
Storage temperature ˚C [˚F] -40 [-40] 85 [185]
Allowable module supply voltage Vdc 7 36
Module sensor supply voltage Vdc 3 12 Sensor voltage drops below the minimum value if
module supply voltage < 7 Vdc. See Sensor power supply
ratings on page 19.
Analog input voltage levels Vdc 36
Allowable output load current
(per pin)
A See individual module date sheets.
Module allowable total output current A See individual module data sheets.
All modules Ingress Protection (IP) rating
*
IP 67
All modules CE rating CE compliant.
*
The PLUS+1
®
modules IP 67 rating is only valid when the module mating connector is in place and unused connector pin positions have sealing plugs
installed.
SC Controller Family environmental testing criteria
Climate environment
Description Applicable standard Comment
Storage temperature IEC 60068-2-1, test Ab, IEC 60068-2-2
test Bb
Operating temperature IEC 60068-2-1, test Ab, IEC 60068-2-2
test Bd
Thermal cycle IEC 60068-2-2, test Na, IEC
60068-2-38 (partial)
Humidity IEC 60068-2-78, IEC 60068-2-30 test
Db
Damp heat steady state and cyclic.
Degree of protection IEC 60529
Technical Information
PLUS+1 SC0XX-1XX Controller Family
Product ratings
20 |
©
Danfoss | June 2016 L1415500 | BC00000235en-US0201
